Joseph B Fay COmpany-I-579 Urban Open Space

General Contractor: JOSEPH B. FAY COMPANY

Project: PITTSBURGH, PA/ALLEGHENY CO I-579 URBAN OPEN SPACE CAP

Number of Beams & Size: (7) 48 X 66 X 121’ thru 111’  @  85.60T thru 79.94T

Number of Beams & Size: (7) 48 X 66 X 110’ thru 104’  @  79.30T thru 75.52T

Number of Beams & Size: (4) 48 X 66 X 102’ thru 101’  @  75.39T thru 74.58T

Number of Beams & Size: (4) 48 X 66 X 58’ thru 56’  @  49.00T thru 47.59T

Number of Beams & Size: (6) 48 X 66 X 121’ thru 116’  @  85.60T thru 82.45T

Number of Beams & Size: (6) 48 X 66 X 100’ thru 98’  @  74.32T thru 72.94T

Number of Beams & Size: (6) 48 X 66 X 98’ thru 95’  @  72.67T thru 71.32T

Number of Beams & Size: (8) 48 X 66 X 65’ thru 59’  @  52.71T thru 49.47T

Number of Beams & Size: (8) 48 X 66 X 71’ thru 66’  @  56.51T thru 53.22T

Number of Beams & Size: (5) 48 X 66 X 93’ thru 92’  @  69.50T thru 68.83T

Number of Beams & Size: (6) 48 X 66 X 95’ thru 93’  @  70.51T thru 69.67T

Number of Beams & Size: (6) 48 X 66 X 97’ thru 95’ @  71.52T thru 70.68T

Number of Beams & Size: (3) 48 X 66 X 96’  @  72.53T

Number of Beams & Size: (3) 48 X 66 X 97’  @   72.02T

Number of Beams & Size: (8) 48 X 66 X 92 thru 94’ @ 70.05T thru 70.94T

Number of Beams & Size: (1) 48 X 66 X 116’  @  83.71T

Number of Beams & Size: (3) 48 X 66 X 90’ thru 92”

Number of Beams & Size: (3) 48 X 66 X 90’ thru 92”  @  69.16T thru 69.87T

Number of Beams & Size: (4) 48 X 66 X 114’ thru 116’ @ 82.97T thru 83.71T

Number of Beams & Size: (6) 48 X 66 X 111’ thru 113’ @ 81.12T thru 82.04T

Number of Beams & Size: (4) 48 X 66 X 109’ thru 110’ @ 79.88T thru 80.44T  unit 1 span 2

Number of Beams & Size: (2) 48 X 66 X 110’ thru 111’ @ 80.75T thru 80.93T  unit 2 span 2

Number of Beams & Size: (4) 48 X 66 X 113’ thru 114’ @ 82.04T thru 82.59T

Number of Beams & Size: (6) 48 X 66 X 105’ thru 107’ @ 77.66T thru 78.58T

Number of Beams & Size: (6) 48 X 66 X 107’ thru 109’ @ 78.77T thru 79.51T
